P100M/18/SM75/DK-RT100 - Regloplas Suomi Sales

BRAND	Regloplas
Product	P100M/18/SM75/DK-RT100
Internal code	IMP4922070
Technical specification	G-P100M-0013 S/N 1179-000034-0108 Temperature control unit 1-circuit device pressurized water device Flow temperature max. 100°C Water heat transfer medium Capacity 1.0 l expansion room - Heating capacity 18 kW Cooling capacity 145 kW Cooling type direct cooling at flow temperature 90 °C at cooling water temperature 20 °C with flow rate per circuit 20 l/min SM75 pump type leak-free magnetic coupling pump flow rate max. 100 l/min Pressure max. 6.0 bar Power consumption 1.5 kW System pressure max. 10 bar Flow pressure max. max. 16 bar RT100 control Pt100 measurement type ports Forward/return G ¾” Cooling water net G ½” total current consumption 31.5 A (at 400V/50Hz) Net water pressure min. 2-6 bar Protection class IP54 Ambient temperature max. 40 °C Dimensions W/H/D 295/711/914 mm Weight approx. 60 kg Color grey, RAL 9006/7016 Continuous sound pressure level <70 dB (A) standard equipment - Automatic water refill - PID controller with high accuracy - SSR for wear-free heating - USB data logger for process logging as a CSV file - Dirt filter in the water supply - Dirt filter in the system return - water circuits made of stainless materials - lockable transport wheels - internal bypass for pump protection - without connection cable, without plug - Dry run protection/level monitoring

Please Contact Us to Order to offer competitive prices and delivery time for Regloplas - P100M/18/SM75/DK-RT100 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Suomi Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
