BRAND | Regloplas |
Product | 90S/6kW/TP20/1K/RT200 |
Description | Single Zone Temperature Control Unit |
Internal code | IMP4740415 |
Technical specification | o Outlet Temperature – Maximum 195º F. o Number of Independent Zones 1 o Heat Transfer Fluid Water o Filling Capacity of Unit 1.5 Gallons o Expansion/Reservoir Capacity – Maximum 1 Gallon o Heating Capacity 6kW o Cooling Capacity at Outlet Temperature – Maximum 38kW @ 175º F. o Pump type / HP TP20 / .75 HP o Flow Rate – Maximum 16 GPM o Outlet Pressure – Maximum 55 PSI o Controller Model RT-200 o Measuring Mode – Standard PT-100 o Operating Voltage 480/3/60 o Control Voltage 230/1/60 o Power Requirements – Maximum 9 Amps @ 480V o Connections - Process Outlet/Inlet G 1/2” o Connections - Cooling Outlet/Inlet G 1/2” o Noise Level <70db |
Please Contact Us to Order to offer competitive prices and delivery time for Regloplas - 90S/6kW/TP20/1K/RT200 Single Zone Temperature Control Unit number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Suomi Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
