XWH 331 S16-X - SMALLEY Suomi Sales

BRAND	SMALLEY
Product	XWH 331 S16-X
Description	Spirolox Retaining Ring
Internal code	IMP1227825
Weight	0.01
Technical specification	Ring Type Internal Ring Housing Diameter (in) 3.312 Groove Diameter (in) 3.416 +/-.006 Groove Width (in) 0.068 +.005/-.000 Free Outside Diameter (in) 3.446 +.030/-.000 Ring Thickness (in) 0.061 +/-.003 Ring Radial Wall (in) 0.188 +.004/-.006 # of Turns 2 Crimp Yes Internal, 316 S/St Ring Shear (lb) 26660 (safety factor of 3) Groove Yield (lb) 12170 (groove material yield strength of 45,000 psi and safety factor of 2) d3 inch. 3,446 mm 87,53 Toll. d3 inch. +0,030 mm +0,76 b inch. 0,188 mm 4,78 Toll. b inch. +0,004/-0,006 mm +0,10/-0,15 s inch. 0,061 mm 1,55 Toll. s inch. +/-0,003 mm +/-0,08 Peso Kg/1000 14,46

Please Contact Us to Order to offer competitive prices and delivery time for SMALLEY - XWH 331 S16-X Spirolox Retaining Ring number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Suomi Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
