| BRAND | Hengesbach |
| Product | TCSG2G_0,25barA_M |
| Description | Pressure transmitter with fixed measuring range |
| Internal code | IMP4607179 |
| Custom code | 90262020 |
| Technical specification | Standard housing from tool 1.4301 Supply voltage 13... 36V DC, output signal 4-20 mA, 2-wire. Linearity ± 0.5% FS Overload protection 2-fold sensor measuring range Process connection: G2G, screw-in thread G1/2" according to ISO 228, sensor inside, drilled out to d=14.5mm. Material tool 1.4435, according to Drawing no. C-20061. Measuring cell sealing: O-ring, material FKM (FDA compliant) Sensor measuring range/set measuring range: 1bar abs/0.25bar abs Electrical connection: Rdst. M12x1, 3-pin According to data sheet PN-TCS... in the currently valid version. |
Please Contact Us to Order to offer competitive prices and delivery time for Hengesbach - TCSG2G_0,25barA_M Pressure transmitter with fixed measuring range number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Suomi Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
