SK5282AF-180LP/4 TF - Nord Suomi Sales

BRAND	Nord
Product	SK5282AF-180LP/4 TF
Internal code	IMP563690
Weight	1
Technical specification	IE3 version (energy efficiency class) - - - - - - - - - - - - - - - - - - - - - - - - - Product designation parallel shaft geared motor Engine speed 1,475 rpm Translation 6.33 Output speed 233,000 rpm Service factor 2.30 Output torque M2 (Nm) 902.00 Power (kW) 22,000 Voltage (V) 400/690 Frequency (Hz) 50 Efficiency class IE3 Operating mode S1 Degree of protection motor IP55 Insulation class F Rated current 1 (AMP) 39.30 Rated current 2 (AMP) 22.70 cosine 1 0.87 Type of gearbox M1 Housing type hollow shaft flange B5 Shaft dimension 60H7 Flange diameter (mm) 350 Ventilation Open, with transport lock Thermal motor protection PTC thermistor, 3x155°C Terminal box position / cable entry 1/I Type of lubricant Mineral oil ISO VG 220 Class oil CLP 220 Amount of lubricant (l) 7,500 Shade 7031 blue-grey Paint type solid paint Painting instructions painting 2 CE Logo Yes

Please Contact Us to Order to offer competitive prices and delivery time for Nord - SK5282AF-180LP/4 TF number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Suomi Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
