| BRAND | Miltac |
| Product | MP110NIVS01A / MP110F312M2066 |
| Description | microswitch |
| Internal code | IMP4839908 |
| Custom code | 85365080 |
| Technical specification | - Size: standard - Operating force: 1.3 N max. - Rest position: 27.2 +/- 2 mm max. - Switch point: 23.1 +/- 2 mm - Maximum end position: - mm max - Differential travel: << 1.6 mm max. - Connections: plug 6.3 x 0.8 mm (vertically downwards), Length of the plug connections 17.8 mm in relation to Switch mounting hole - Mounting holes: 2x D 3.6 mm +0.2 mm Tol. - Circuit diagram: Changer (CO) - Actuator: 2A actuator with sealing membrane on Plunger, long leaf spring lever, l=30.0 mm - Contact material: solid silver rivet - Housing material: - (white) - Approval: - - Protection class: IP00 (housing: IP67) - Special feature: customer-specific special version - - Long recessed plug connections - - Mounting hole D3.6 mm (2x) - - Switch hysteresis as with a patterned switch MP120-2A |
Please Contact Us to Order to offer competitive prices and delivery time for Miltac - MP110NIVS01A / MP110F312M2066 microswitch number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Suomi Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
