BRAND | Merkle |
Product | MBZ 160.25/16.02.201.020 OM.V |
Internal code | IMP4977605 |
Technical specification | Article 169064 AHP BLOCK CYLINDER MBZ 160.25/16.02.201.020 OM.V Weight 0.7 kg Customs tariff no./ origin 84122180/DE Type block cylinder for magnetic field sensor cylinder type designation MBZ 160 Piston diameter 25 mm Bar diameter 16mm Design 02 = 4 mounting holes, lowered at the rear, connection: pipe thread Function type 201 = double-acting Stroke 20 mm OM switch = prepared for magnetic field sensors Viton sealing type - up to max. 180°C max. operating pressure 250 bar up to max. 3 million double strokes |
Please Contact Us to Order to offer competitive prices and delivery time for Merkle - MBZ 160.25/16.02.201.020 OM.V number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Suomi Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
