| BRAND | Xecro |
| Product | IR21S-PO100-A12 |
| Description | Inductive Ring-Sensor |
| Internal code | IMP1330498 |
| Weight | 1 |
| Technical specification | Ring diameter 21.1 mm Resolution Ø 2.5 mm (steel ball) Static operating principle Operating voltage 10-30 V DC, reverse polarity protection Self-current consumption < 10 mA current carrying capacity 200 mA, short circuit protection Voltage drop < 2 V at 200 mA Multi-turn pot sensitivity setting. Part speed < 20 m/s Response/drop time 0.5/10 ms Ambient temperature -25 ºC to + 70 ºC Protection class IP 67 PBT housing; ring: nylon Installation distance to metal > 5 mm Connection M12 plug, 4-pin |
Please Contact Us to Order to offer competitive prices and delivery time for Xecro - IR21S-PO100-A12 Inductive Ring-Sensor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Suomi Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
