| BRAND | ProMinent |
| Product | GALA1008NPB200UA003000 |
| Description | Magnetdosierpumpe GALa |
| Internal code | IMP561592 |
| Weight | 1 |
| Technical specification | mit stufenloser Hublängeneinstellung, digitalgenau einstellbarer Hubfrequenz von 0 bis 100% über Tastatur und LCD-Display. Mit externer Ansteuerungsmöglichkeit über potentialfreie Kontakte, Anschluß für 2-stufigen Niveauschalter, Dosierüberwachungseingang mit einstellbarer Anzahl der Fehlhübe, wählbarer Anzeige der Fördermenge als l/h oder Hübe/Minute, mit programmierbaren Druckstufen. Optional mit externer Ansteuerung über Normsignal 0/4..20 mA, Impulsüber-/untersetzung. Hinweis: bei der Ausführung GALA 1005 und 1605 mit Dosierkopf aus Edelstahl, abweichende Anschlussweite 6 x 4 mm. Bei HV-Köpfen abweichende Anschlussweite DN10 Bestellung nach Identcode. Identcode : GALA1008NPB200UA003000 Baureihe : GALA Gamma/L- Pumpe Version A Pumpentyp : 1008 10 bar , 8 l/h St.Anschl. 8x5 Dosierkopfwerkstoff : NP Plexiglas / PVC Dichtungswerkstoff : B Standard Membr./Viton-B Dicht. Dosierkopfausführung: 2 m.Entlüftung , o.Ventilfeder Hydraulischer Anschl: 0 Standard-Anschluss Ausführung : 0 mit PM-Logo Ausführung Leistungs: U Universalsteuerung 100 - 240 V Kabel und Stecker : A 2m Europa Relaisfunktion : 0 ohne Relais Zubehör : 0 ohne Zubehör Steuerungsvariante : 3 Manual + Cont. + P.C. + A.S. Sicherheitsoptionen : 0 ohne Zugangskontrolle Dosierüberwachung : 0 Dosierüberwachung dynamisch Fernstop : 0 Pause Öffner, Niveau Öffner Zulassung : 01 CE Frequenz : 50/60Hz Spannung : 100-230V Leistung : 23W Schutzart : IP65 Förderleistung : 6,8l/h Gegendruck : 10bar |
Please Contact Us to Order to offer competitive prices and delivery time for ProMinent - GALA1008NPB200UA003000 Magnetdosierpumpe GALa number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Suomi Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Chlorine sensor Amperometric two-electrode cell with diaphragm cap, flow-independent, stable zero point, integr. Temperature compensation. Typical applications: drinking water, dechlorination Terminal / diameter: mm 2-pol./25 Measuring range: 0,01..0,5 mg / liter Parameter: free chlorine pH range: 5,5..8,0 temperature / pressure: 5..45 degrees C / 1 bar Flow: 30..60 L / h Installation length: 221 mm Order number: 792927
Conductivity sensor DE01, DE02, HY01, HY02, TCS
Chlorine Analyzer (Dulcometer) Power Supply 230VAC/0.05A
Controller DULCOMETER D1Cb Identcode: D1CBW00601000VD1201G00EN Series: D1Cb D1Cb DULCOMETER Mounting: W wall mounting IP65 Design: 00 + LCD keyboard, with PM Logo Operating voltage: 6 90-253 VAC 50/60 Hz Approvals: 01 CE mark Hardware extension: 0 No Hardware extension: 0 No External connection: 0 No Software preset: preset V software Preset Meas: D chlorine dioxide Terminal of the Meßgröß: 1 mA Correction quantity: 2 Temp.Pt100 via terminal (pH, conductivity) Control input: 0 No (default) Signal output: 1 1 analogue signal output 0 / 4-20mA Power activation G Alarm + 2 limit values (Standard) Pump control: 0 Without (standard) Control behavior: 0 No (default) Default speech bubble: EN English (British) Frequency: 50/60 HZ Voltage: 90-253 VAC Power: 12 W ~ Protection: IP65
DOSING PUMP
DHV-RM REPLACED BY > DHV-U DN25 PVT
VALVE, RLF, THD, 1.5 ", PROMNT, DHVRM, 1000056
PUMP
Pressure-sustaining valve
spare
(Series: DLTA Delta Optodrive- version A, pump type: 02bar 0280, 75 l / h conn.DN10)
delta -optodrive ProMinent delta(R) Magnet-Membrandosierpumpe
Series: DLTA Delta Optodrive- Version A Pump type: 04bar 0450, 49 l / h conn.DN10 Dosing head: PV PVDF Seal material: T Standardmembr. / PTFE sealing. Dosing head: 2 m.Entlüftung, o.Ventilfeder Hydraulic Conn: 0 standard connection Diaphragm failure monitor: 0 None Version: 0 With PM-Logo Execution performance: U universal controller 100 - 240 V Cables and connectors: A 2m Europe Relay function: 1 alarm sloping Accessories: 1 Dos.v. 1/2 "and Fußv. Control variant: 3 Manual + analog current PC + Security Options: 0 no access control Language: English EN Remote Stop: 0 Pause break contact, level Opener Admission: 01 CE Frequency: 50-60Hz Voltage: 100-240V Power: 73W Protection: IP65 Capacity: 49,0l / h Back pressure: 04bar
Series: DLTA Delta Optodrive- Version A Pump Type: 1020 10bar, 19,1l / h con.12x9 / SS12x10 Dosing head: PV PVDF Seal material: T Standardmembr. / PTFE sealing. Dosing head: 3 m.Entlüftung, m.Ventilfeder Hydraulic Conn: 0 standard connection Diaphragm failure monitor: 0 None Version: 0 With PM-Logo Execution performance: U universal controller 100 - 240 V Cables and connectors: A 2m Europe Relay function: 0 without relay Accessories: 0 without accessories Control variant: M control module 4 -20 mA Security Options: 0 no access control Language: DE German Remote Stop: 0 Pause break contact, level Opener Admission: 01 CE Frequency: 50-60Hz Voltage: 100-240V Power: 73W Protection: IP65 Capacity: 19,1l / h Back pressure: 10bar
Series: DLTA Delta Optodrive- Version A Pump Type: 1612 16bar, 11,3l / h conn.8x5 / SS8x7 Dosing head: SS stainless steel Seal material: T Standardmembr. / PTFE sealing. Dosing head: 0 o.Entlüftung, o.Ventilfeder Hydraulic Conn: 0 standard connection Diaphragm failure monitor: 0 None Version: 0 With PM-Logo Execution performance: U universal controller 100 - 240 V Cables and connectors: A 2m Europe Relay function: 3 Fail safe appealing Accessories: 0 without accessories Control variant: 3 Manual + analog current PC + Security Options: 0 no access control Language: English EN Remote Stop: 0 Pause break contact, level Opener Admission: 01 CE Frequency: 50-60Hz Voltage: 100-240V Power: 73W Protection: IP65 Capacity: 11,3l / h Back pressure: 16bar
Plug valve Order number: 1018190
dosing container
Fasspumpe
type: D1C b Mounting: Wall version Power supply: 220 V, 50/60 Hz; IP 65 Dimensions (WxHxD): 200x200x76 mm
air driven double diaphragm pump
GALA0420TTT000UA100000 GALA GAMMA/L- PUMPE VERSION A
Pump type: 0420 4 bar, 20 l / h St.Anschl.12x9 Dosing head: TT PTFE + 25% carbon Seal material: T standard Membr./ PTFE sealing. Dosing head: 0 o.Entlüftung, o.Ventilfeder Hydraulic Conn: 0 standard connection Version: 0 With PM-Logo Execution performance: U universal controller 100 - 240 V Cables and connectors: A 2m Europe Relay function: 1 alarm sloping Accessories: 0 without accessories Control variant: 0 Manual + Cont. 1: 1 Security Options: 0 no access control Dosing monitoring: 0 dosing monitor dynamically Remote Stop: 0 Pause break contact, level Opener Admission: 01 CE Frequency: 50 / 60Hz Voltage: 100-230V Power: 23W Protection: IP65 Capacity: 17,1l / h Back pressure: 04bar
