BRAND | Georgin |
Product | 309015 FC34CX |
Description | Capillary temperature switch with remote sensor (expansion principle) |
Internal code | IMP4502872 |
Custom code | 90321080 |
Technical specification | FC34CX capillary temperature switch with Remote sensor (expansion principle) F series capillary temperature switch Protection class: IP 66 Case: Mazak, epoxy coated, stainless steel screws Measurement range: -50°C... +10°C max. temperature: 55°C Sensor element: 2 m capillary tube, piston d: 14x150mm Material: 316L st.st. O2 cleaning Capillary tube protection (optional): none 2 simultaneous tropical-resistant SPDT contacts adjustable hysteresis (low/high of measurement range): 13°C -30°C/2.2°C - 10°C Current: 10A/240VAC - 0.5A/110VDC electrical connection: 1/2" NPTF Special feature: stainless steel nameplate Product Code: 0FC34MCSP00A0 Customs tariff number: 9032 1080 Country of origin: France/EU |
Discover the superior quality and performance of the Georgin 309015 FC34CX with Impexron GMBH in Suomi . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 309015 FC34CX is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 309015 FC34CX :
At Impexron GMBH , we offer the 309015 FC34CX at competitive prices and with the fastest delivery times across Suomi . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 309015 FC34CX ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Georgin products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Pressure switch F series protection : IP66 / ATEX intrinsic safety housing : mazak, epoxy painted range : 5 to 50 bar max. pressure : 80 bar sensing element : bellows material : 316L st. st.
Pressure switch F series
Pressure switch
Pressure switch F series
(Gauge pressure transmitter... GR/GA series housting: stainless steel / protection: IP65 range : 0...50 bar maxi pressure : 150 bar sensor: ceramic cell on viton gasket process connection : 1/2" BSPM - st.st. 316 L electrical connector : DIN43650 power supply : 10...30Vdc output signal : 4...20 mA max. global error : 0.5% FS --------ATEX information------------ EC type examination certificate LCIE 01 ATEX 6137X Ex ia IIC T6 or T5 Ga (-30 Ta 55 or 70Celsius) Ex ia IIIC T80Celsius or T95Celsius Da (-30 Ta 55 Celsius or 70 Celsius Groupe II - category 1GD - Zones 0-1-2 or 20-21-2: Ex ia I - group I (MInes) -CAtegory Mi Production Notification LCIE 02 ATEX Q 8023 See leaflet for a safe use)
Drucktransmitter
Drucktransmitter
Drucktransmitter
SWITCH PRESSURE
(Pressure switch)
pressure Switch
(Pressure switch P series protection : IP66 housing : mazak, epoxy painted-st.st. screws range : 10 to 90 bar max. pressure : 250 bar sensing element : bellows material : 316L st. st. process connection : 1/2"NPTM switch : 2 simultaneous SPDT, dry contact adjust. deadband current rating : 5A/240VAC - 0.5A/110VDC cable gland : polyamid M20 (Ø7.5-13) features: st. st. tag plate)
material : PBT Goods of French / E.U. origin European Customs Tariff Pressure Switch : 9032 2000
Druckschalter mit Flansch
Pressure indicator
pressure switch
Manometer
Gauge pressure transmitter
Gauge pressure transmitter
Gauge pressure transmitter
Gauge pressure transmitter
Gauge pressure transmitter
Gauge pressure transmitter
Gauge pressure transmitter
Differential pressure transmitter
Differential pressure transmitter
