ERCH/III/38-1,6 - Schniewindt Suomi Sales

BRAND	Schniewindt
Product	ERCH/III/38-1,6
Description	screw-in heater
Internal code	IMP3816277
Weight	3
Technical specification	Article no. 7881160930383 CNC screw-in heater Type ERCH/III/38-1.6 *as manufactured under FA17-52880 Voltage (V) 400 Power (kW) 1.6 Power tolerance Special tolerance +4.5/-9% based on: heat output Star circuit (3N~) Protection class IP 54 ------ ------- Horizontal installation Installation length (mm) 380 +Tolerance length 0 -Tolerance length (mm) 80 DIN ISO 228 G2"/SW 70 screw connection Material screw connection MS soldered ---------------------- heating element ---------------------- Number of tubular heaters (RHK) 3 RHK diameter (mm) 11.5 Surface load W/cm2 2.4 Material for RHK 1.4571/1.4404 Closure type RHK GISO-G ------------------------------------ Hood/swivel bowl ------------------------------------ M20 load cable screw Hood (mm) 60x68 Hood material galvanised steel operating conditions ------------------------------------ Medium flowing air Operating temperature (oC) (TS) max.100 max.allowable pressure (PS) 10 bar g Maximum permissible temperature must be guaranteed on a customer-specific basis - the surface 700 oC -in the 100 o C connection area

Please Contact Us to Order to offer competitive prices and delivery time for Schniewindt - ERCH/III/38-1,6 screw-in heater number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Suomi Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
