BRAND	FSG Fernsteuergeräte
Product	5754Z03-160.009
Description	Magnetic Rotary Encoder
Internal code	IMP4183213
Custom code	90318020
Technical specification	Type: MH1023-MU/i-01 in the case of synchro size 23 Version according to 5754Z03-160M009E with DNV GL certificate TAA000023V Degree of protection IP 68 with molded electronics Measuring range: max. 0 - 360° Resolution 14 bit/360° preset to 0 - 90° Output: 4-20mA at max. 600 Ohm Active-angle and direction of rotation via Programmable connection cables Output in 4-wire technology with galvanic isolation Power supply: 18 - 33V DC with cable connection, length 2.5m Shaft diameter 20mm, Length from cushion 24mm

Please Contact Us to Order to offer competitive prices and delivery time for FSG Fernsteuergeräte - 5754Z03-160.009 Magnetic Rotary Encoder number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Suomi Industrial products Market.
