00L/20KW/FM65/1K/RT200 - Regloplas Suomi Sales

BRAND	Regloplas
Product	00L/20KW/FM65/1K/RT200
Internal code	IMP4888425
Technical specification	Technical Data: o Outlet Temperature – Maximum 570° F. o Number of Independent Zones 1 o Heat Transfer Fluid Thermal Oil o Filling Capacity of Unit 4 Gallons o Expansion/Reservoir Capacity – Maximum 5.3 Gallons o Heating Capacity 20kW o Cooling Capacity at Outlet Temperature – Maximum 160kW @ 535º F. o Pump Model / HP FM65 / 4 HP o Flow Rate – Maximum 23 GPM o Outlet Pressure – Maximum 145 PSI o Controller Model RT200 o Solid State Relays Standard o Second Level Switch in Reservoir Standard o Measuring Mode PT-100 o Operating Voltage 480V/3/60 o Control Voltage 230V/1/60 o Power Requirements – Maximum 31 Amps @ 480V o Connections - Oil Outlet/Inlet NPT 3/4” o Connections - Water Outlet/Inlet NPT 3/4” o Noise Level <70db

Please Contact Us to Order to offer competitive prices and delivery time for Regloplas - 00L/20KW/FM65/1K/RT200 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Suomi Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
